McHale Fusion 2 drive systems section

13-16

McHale Fusion 2 round baler wrapper technical service manual

Issue 1: 0208

Adjustment length for

2000 Nm =

50mm –0 +0.3

13.7.1 Slip clutch setting K64/22
