McHale Fusion 2 - Wrapper Counting Errors; Wrapper Indexing Issues

McHale Fusion 2 troubleshooting section
14-10
McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
14.21 Wrapper not counting/ counting incorrectly
14.22 Wrapper wont index by a half rotation from the index button
(button held down for 2 seconds)
Reason Solution Reference Section
30 mm sensor
damaged
Check and replace
sensor if necessary
11.4.2
Dispenser position out
of line
Adjust dispenser closer
to sensor on its slots
Sensor position Adjust sensor closer to
dispenser so that it can
see the dispenser
11..4.2
Reason Solution Reference Section
Box is not in auto Switch control box to
auto
11.6
Oil is not allowed to
flow
Check hydraulics' and
ensure they are turned
on
Refer to tractor
operator manual
Dispenser has moved
in its slotted position in
the ring and the sensor
can not see it
Re-position the
dispenser which is not
being picked up closer
to the sensor
For sensor
measurement distance
refer to 11.4.2
The 30 mm sensor has
been moved out of
position
Re-position the 30 mm
sensor closer to the dis-
penser
11.4.2
The 30 mm sensor is
damaged
Check for visible
damage
Conduct an input check
and replace if
necessary
11.4.2
