Address Description Current value
056 020 MEASO: Function group MEASO With
031 074 MEASO: General enable USER Yes
053 000 MEASO: Fct. assignm. A-1 MAIN: Voltage V p.u.
010 114 MEASO: Hold time output A-1 1.00 s
037 104 MEASO: Scaled min. val. A-1 0.013 (corresponds with 0.02 Vnom)
037 105 MEASO: Scaled knee val. A-1 0.067 (corresponds with 0.10 Vnom)
037 106 MEASO: Scaled max. val. A-1 0.667 (corresponds with 1.00 Vnom)
037 107 MEASO: AnOut min. val. A-1 4 mA
037 108 MEASO: AnOut knee point A-1 16 mA
037 109 MEASO: AnOut max. val. A-1 18 mA
By setting MEASO: AnOut min. val. A-1, the user can specify the output
current that will be output when values are smaller than or equal to the set
minimum measured value to be transmitted. The setting at MEASO: AnOut
max. val. A-1 defines the output current that is output for the maximum
measured value to be transmitted. By defining the knee-point, the user can
obtain two characteristic curve sections with different slopes. When entering this
setting the user must keep in mind that only a rising/rising or falling/falling curve
sense is permitted (peaky or vee shapes not allowed). If the setting was not
properly entered, the signal SFMON: Invalid scaling A-1 will be issued.
A check of the set characteristic and its acceptance by the P634, if the setting was
properly entered, will only occur after the P634 is switched on-line again (with the
setting MAIN: Device on-line).
P634 3 Operation
3-56 P634/EN M/R-42-A // P634‑311‑653
