Micom P634 - Page 113

0
2
4
6
8
10
12
14
16
18
20
0 0.02 0.1 1 1.2 1.3 1.4 1.5
Ia / mA
Min.
output value
Knee point
output value
Max.
output value
Mx,scal0.013
0.067
0.667
Vnom
1.0
19Z5265A
Fig. 3-35: Example of a characteristic curve for analog measured data output . In this example the range starting
value is = 0; also possible is directional-signed output (see corresponding example in section BCD Measured Data
Output).
3 Operation P634
P634/EN M/R-42-A // P634‑311‑653 3-57
