Micom P634 - Page 249

64Z5197A
V/f:
Trip signal tV/f(t)
[ 041 233 ]
V/f:
Starting V/f(t)
[ 041 232 ]
V/f:
Trip signal tV/f(t)
[ 041 233 ]
V/f:
Starting V/f(t)
[ 041 232 ]
Determ. trip time
Determ. trip time
Parameter
set 1
set 2
set 3
set 4
V/f:
Reset time PSx
081 230
082 230
083 230
084 230
Case A
Case B
5.5 s
2 s
2 s
4 s
6 s
2 s
4 s
6 s
2 s 2 s
Fig. 3-146: Buffer memory content during a starting
3 Operation
P634
P634/EN M/R-42-A // P634‑311‑653 3-193
