D5Z50CCA
LOGIC:
Output n
LOGIC:
Output n (t)
t1
t1
Fig. 3-181: Operating mode 5: Minimum time (Minimum time). (This diagram is also valid for LOG_2, if the signal
parameters are replaced by the corresponding ones from LOG_2 .)
Through appropriate configuration, it is possible to assign the function of a binary
input signal to each output of a logic operation. The output of the logic operation
then has the same effect as if the binary signal input to which this function has
been assigned were triggered.
3 Operation P634
P634/EN M/R-42-A // P634‑311‑653 3-225
