Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
COMM1: Ind./cl. analog inp.
003 235
060 000: MAIN: Without function Fig. 3-11, (p. 3-16)
[spacer]
Selection of data points and data classes for object 30 – analog inputs.
Assignment of indices is made in the order of selection, beginning with 0.
Note: This setting is hidden unless the DNP 3.0 protocol is enabled.
[spacer]
COMM1: Ind./cl. analog outp
003 236
060 000: MAIN: Without function Fig. 3-11, (p. 3-16)
[spacer]
Selection of data points and data classes for object 40 – analog outputs.
Assignment of indices is made in the order of selection, beginning with 0.
Note: This setting is hidden unless the DNP 3.0 protocol is enabled.
[spacer]
COMM1: Delta meas.v. (DNP3)
003 250
16 0 255 Fig. 3-11, (p. 3-16)
[spacer]
Initialization value of threshold values for transmission of measured values in
object 30. The threshold values can be changed separately by the master for
each measured value by writing to object 34, 'analog input reporting deadband'.
Note: This setting is hidden unless the DNP 3.0 protocol is enabled.
[spacer]
COMM1: Delta t (DNP3)
003 248
5 1 120 s Fig. 3-11, (p. 3-16)
[spacer]
Cycle time for updating DNP object 30 (analog inputs).
Note: This setting is hidden unless the DNP 3.0 protocol is enabled.
[spacer]
COMM1: Command selection
103 042
060 000: MAIN: Without function Fig. 3-12, (p. 3-17)
[spacer]
Selection of commands to be issued via the COURIER protocol.
Note: This setting is hidden unless the COURIER protocol is enabled.
[spacer]
COMM1: Signal selection
103 043
060 000: MAIN: Without function Fig. 3-12, (p. 3-17)
[spacer]
Selection of signals to be transmitted via the COURIER protocol.
Note: This setting is hidden unless the COURIER protocol is enabled.
[spacer]
COMM1: Meas. val. selection
103 044
060 000: MAIN: Without function Fig. 3-12, (p. 3-17)
[spacer]
Selection of measured values to be transmitted via the Courier protocol.
Note: This setting is hidden unless the Courier protocol is enabled.
[spacer]
COMM1: Parameter selection
103 045
060 000: MAIN: Without function Fig. 3-12, (p. 3-17)
[spacer]
Selection of settings to be altered via the Courier protocol.
Note: This setting is hidden unless the Courier protocol is enabled.
7 Settings P634
P634/EN M/R-42-A // P634‑311‑653 7-27
