Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
COMM1: Link Confirm. Mode
003 243
1: Multi-frame fragment Fig. 3-11, (p. 3-16)
[spacer]
Setting for the acknowledgment mode of the link layer.
Note: This setting is hidden unless the DNP 3.0 protocol is enabled.
[spacer]
COMM1: Link Confirm.Timeout
003 244
0.10 0.05 2.54 s Fig. 3-11, (p. 3-16)
[spacer]
Setting for the time period within which the master must acknowledge at the
link layer.
Note: This setting is hidden unless the DNP 3.0 protocol is enabled.
[spacer]
COMM1: Link Max. Retries
003 245
2 1 10 Fig. 3-11, (p. 3-16)
[spacer]
Number of repetitions that are carried out on the link layer if errors have
occurred during transmission (such as failure to acknowledge).
Note: This setting is hidden unless the DNP 3.0 protocol is enabled.
[spacer]
COMM1: Appl.Confirm.Timeout
003 246
5.0 0.5 25.4 s Fig. 3-11, (p. 3-16)
[spacer]
Setting for the time period within which the master must acknowledge at the
application layer.
Note: This setting is hidden unless the DNP 3.0 protocol is enabled.
[spacer]
COMM1: Appl. Need Time Del.
003 247
60 5 254 s Fig. 3-11, (p. 3-16)
[spacer]
Time interval within which the slave requests time synchronization cyclically
from the master.
Note: This setting is hidden unless the DNP 3.0 protocol is enabled.
[spacer]
COMM1: Ind./cl. bin. inputs
003 232
060 000: MAIN: Without function Fig. 3-11, (p. 3-16)
[spacer]
Selection of data points and data classes for object 1 – binary inputs.
Assignment of indices is made in the order of selection, beginning with 0.
Note: This setting is hidden unless the DNP 3.0 protocol is enabled.
[spacer]
COMM1: Ind./cl. bin.outputs
003 233
060 000: MAIN: Without function Fig. 3-11, (p. 3-16)
[spacer]
Selection of data points and data classes for object 10 – binary outputs.
Assignment of indices is made in the order of selection, beginning with 0.
Note: This setting is hidden unless the DNP 3.0 protocol is enabled.
P634 7 Settings
7-26 P634/EN M/R-42-A // P634‑311‑653
