Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MEASO: AnOut max. val. A-2
037 115
20.00 0.00 20.00 mA
[spacer]
Output current range for measured values in the range “measured values to be
issued”; designation in the data model: “An-Out min. val. Ax” ... “An-Out max.
val. Ax”
Output current to be set for measured values ≤ Mx,min; designation in the data
model: “An-Out min. val. Ax”
Output current to be set for measured values ≥ Mx,max; designation in the data
model: “An-Out max. val. Ax”
Output current to be set for measured values = Mx,knee; designation in the data
model: “AnOut knee point Ax”
with:
Mx,min ... Mx,max: measured values to be issued
[spacer]
MEASO: Output value 1
037 120
0.00 0.00 100.00 %
[spacer]
MEASO: Output value 2
037 121
0.00 0.00 100.00 %
[spacer]
MEASO: Output value 3
037 122
0.00 0.00 100.00 %
[spacer]
Measured values of external devices, which must be scaled to 0 to 100%, can be
issued.
P634 7 Settings
7-62 P634/EN M/R-42-A // P634‑311‑653
