Micom P634 - Page 417

Parameter Address
Default Min Max Unit Logic Diagram
LED indicators
LED: Fct.assig. H 1 green
085 184
060 001: MAIN: Healthy
[spacer]
Display of the operational readiness of the protection device.
The function MAIN: Healthy is permanently assigned.
[spacer]
LED: Fct.assig. H 2 yell.
085 001
004 065: MAIN: Blocked/faulty
[spacer]
Display of the function assigned to LED indicator H 2.
The function MAIN: Blocked/faulty is permanently assigned.
[spacer]
LED: Fct.assig. H 3 yell.
085 004
036 070: SFMON: Warning (LED)
[spacer]
Display of the function assigned to LED indicator H 3.
The function SFMON: Warning (LED) is permanently assigned.
[spacer]
LED: Fct.assig. H 4 red
085 007
036 251: MAIN: Gen. trip signal
[spacer]
LED: Fct.assig. H 4 green
085 057
060 000: MAIN: Without function
[spacer]
LED: Fct.assig. H 5 red
085 010
060 000: MAIN: Without function
[spacer]
LED: Fct.assig. H 5 green
085 060
060 000: MAIN: Without function
[spacer]
LED: Fct.assig. H 6 red
085 013
060 000: MAIN: Without function
[spacer]
LED: Fct.assig. H 6 green
085 063
060 000: MAIN: Without function
[spacer]
LED: Fct.assig. H 7 red
085 016
060 000: MAIN: Without function
[spacer]
LED: Fct.assig. H 7 green
085 066
060 000: MAIN: Without function
[spacer]
LED: Fct.assig. H 8 red
085 019
060 000: MAIN: Without function
[spacer]
LED: Fct.assig. H 8 green
085 069
060 000: MAIN: Without function
[spacer]
LED: Fct.assig. H 9 red
085 022
060 000: MAIN: Without function
[spacer]
LED: Fct.assig. H 9 green
085 072
060 000: MAIN: Without function
