Micom P634 - Page 485

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
LOGIC: Time t2 output116
045 207
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t2 output117
045 211
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t2 output118
045 215
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t2 output119
045 219
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t2 output120
045 223
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t2 output121
045 227
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t2 output122
045 231
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t2 output123
045 235
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t2 output124
045 239
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t2 output125
045 243
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t2 output126
045 247
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t2 output127
045 251
0.00 0.00 600.00 s
[spacer]
LOGIC: Time t2 output128
045 255
0.00 0.00 600.00 s
[spacer]
Settings for timer stage t2 for the respective outputs.
Note: This setting has no effect in the “minimum time” operating mode.
[spacer]
LOGIC: Sig.assig. outp. 1
044 000
061 000: MAIN: Without function Fig. 3-182, (p. 3-226)
[spacer]
LOGIC: Sig.assig. outp. 2
044 002
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig. outp. 3
044 004
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig. outp. 4
044 006
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig. outp. 5
044 008
061 000: MAIN: Without function
