Micom P634 - Page 534

Parameter Address
Default Min Max Unit Logic Diagram
Overfluxing protec‐
tion
V/f: Enable PSx
081 210 082 210 083 210 084 210
0: No Fig. 3-141, (p. 3-190)
[spacer]
This setting defines the parameter subset in which overfluxing protection is
enabled.
[spacer]
V/f: V/f> (alarm) PSx
081 211 082 211 083 211 084 211
1.05 1.00 1.20 Vnom/
fnom
[spacer]
Setting for the operate value of the warning stage.
[spacer]
V/f: V/f(t)> PSx
081 212 082 212 083 212 084 212
1.10 1.05 1.50 Vnom/
fnom
Fig. 3-147, (p. 3-194)
[spacer]
Setting for the operate value of the time-dependent elements.
[spacer]
V/f: V/f>> PSx
081 213 082 213 083 213 084 213
Blocked 1.05 1.60 Vnom/
fnom
Fig. 3-144, (p. 3-191)
[spacer]
Setting for the operate value of the time-independent elements.
[spacer]
V/f: tV/f> PSx
081 214 082 214 083 214 084 214
1 0 10000 s
[spacer]
Setting for the operate delay of the warning stage.
[spacer]
V/f: t at V/f=1.05 PSx
081 217 082 217 083 217 084 217
72.8 1.0 6000.0 s Fig. 3-147, (p. 3-194)
[spacer]
V/f: t at V/f=1.10 PSx
081 218 082 218 083 218 084 218
18.8 1.0 6000.0 s Fig. 3-147, (p. 3-194)
[spacer]
V/f: t at V/f=1.15 PSx
081 219 082 219 083 219 084 219
8.8 1.0 6000.0 s Fig. 3-147, (p. 3-194)
[spacer]
V/f: t at V/f=1.20 PSx
081 220 082 220 083 220 084 220
5.3 1.0 6000.0 s Fig. 3-147, (p. 3-194)
[spacer]
V/f: t at V/f=1.25 PSx
081 221 082 221 083 221 084 221
3.7 1.0 6000.0 s Fig. 3-147, (p. 3-194)
[spacer]
V/f: t at V/f=1.30 PSx
081 222 082 222 083 222 084 222
2.8 1.0 6000.0 s Fig. 3-147, (p. 3-194)
[spacer]
V/f: t at V/f=1.35 PSx
081 223 082 223 083 223 084 223
2.3 1.0 6000.0 s Fig. 3-147, (p. 3-194)
[spacer]
V/f: t at V/f=1.40 PSx
081 224 082 224 083 224 084 224
1.9 1.0 6000.0 s Fig. 3-147, (p. 3-194)
[spacer]
V/f: t at V/f=1.45 PSx
081 225 082 225 083 225 084 225
1.7 1.0 6000.0 s Fig. 3-147, (p. 3-194)
P634 7 Settings
7-180 P634/EN M/R-42-A // P634‑311‑653
