Micom P634 - Page 548

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Current IC,d p.u.
007 034
Not measured 0.000 25.000 Inom
[spacer]
Display of phase current A/B/C for the respective end, referred to In.
[spacer]
MAIN: Current Ineg a p.u.
005 126
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current Ineg b p.u.
005 130
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current Ineg c p.u.
005 137
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current Ineg d p.u.
005 145
Not measured 0.000 25.000 Inom
[spacer]
Display of the negative-sequence current of the respective end, referred to I
nom
.
[spacer]
MAIN: Current Ipos a p.u.
005 128
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current Ipos b p.u.
005 135
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current Ipos c p.u.
005 139
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current Ipos d p.u.
005 147
Not measured 0.000 25.000 Inom
[spacer]
Display of the positive-sequence current (for the respective end), referred to
I
nom
.
[spacer]
MAIN: Current IN,a p.u.
005 141
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current IN,b p.u.
005 142
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current IN,c p.u.
005 143
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current IN,d p.u.
005 144
Not measured 0.000 25.000 Inom Fig. 3-48, (p. 3-79)
[spacer]
Display of the residual current calculated by the P634 from the sum of the phase
currents of the respective end, referred to I
nom
.
[spacer]
MAIN: Current IY,a p.u.
005 151
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Current IY,b p.u.
005 152
Not measured 0.000 25.000 Inom
P634 8 Information and Control Functions
8-10 P634/EN M/R-42-A // P634‑311‑653
