Micom P634 - Page 570

Parameter Address
Default Min Max Unit Logic Diagram
Binary and analog
output
OUTP: State K 1201
151 008
0: Inactive
[spacer]
OUTP: State K 1202
151 011
0: Inactive
[spacer]
OUTP: State K 1601
171 001
0: Inactive
[spacer]
OUTP: State K 1602
171 005
0: Inactive
[spacer]
OUTP: State K 1603
171 009
0: Inactive
[spacer]
OUTP: State K 1604
171 013
0: Inactive
[spacer]
OUTP: State K 1605
171 017
0: Inactive
[spacer]
OUTP: State K 1606
171 021
0: Inactive
[spacer]
OUTP: State K 1607
171 025
0: Inactive
[spacer]
OUTP: State K 1608
171 029
0: Inactive
[spacer]
OUTP: State K 1801
173 001
0: Inactive
[spacer]
OUTP: State K 1802
173 005
0: Inactive
[spacer]
OUTP: State K 1803
173 009
0: Inactive
[spacer]
OUTP: State K 1804
173 013
0: Inactive
[spacer]
OUTP: State K 1805
173 017
0: Inactive
[spacer]
OUTP: State K 1806
173 021
0: Inactive
[spacer]
OUTP: State K 2001
151 200
0: Inactive
[spacer]
OUTP: State K 2002
151 203
0: Inactive
P634 8 Information and Control Functions
8-32 P634/EN M/R-42-A // P634‑311‑653
