Micom P634 - Page 612

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Blocking 3 EXT
040 116
0: No
[spacer]
MAIN: Blocking 4 EXT
040 117
0: No
[spacer]
MAIN: M.c.b. trip V EXT
004 061
0: No
[spacer]
MAIN: Trip cmd. block. EXT
036 045
0: No
[spacer]
MAIN: Man. trip cmd. EXT
037 018
0: No
[spacer]
MAIN: Switch dyn.param.EXT
036 033
0: No
[spacer]
MAIN: Test mode EXT
037 070
0: No
[spacer]
MAIN: Time switching EXT
003 096
0: Standard time
[spacer]
MAIN: Min-pulse clock EXT
060 060
0: No
[spacer]
MAIN: Healthy
060 001
1: Yes
[spacer]
Signal that the protection unit is operational. By default this signal is linked to
LED: Fct.assig. H 1 green.
[spacer]
MAIN: Time synchronized
009 109
0: No
[spacer]
MAIN: Blocked/faulty
004 065
1: Yes Fig. 3-59, (p. 3-91)
[spacer]
MAIN: Protect. not ready
004 060
1: Yes Fig. 3-59, (p. 3-91)
[spacer]
MAIN: Test mode
037 071
0: No Fig. 3-68, (p. 3-99)
[spacer]
MAIN: Prot. ext. enabled
003 028
0: No Fig. 3-55, (p. 3-87)
[spacer]
MAIN: Prot. ext. disabled
038 046
1: Yes Fig. 3-55, (p. 3-87)
[spacer]
MAIN: Dynam. param. active
040 090
0: No Fig. 3-56, (p. 3-88)
[spacer]
MAIN: CB1 open 3p
031 040
0: No
P634 8 Information and Control Functions
8-74 P634/EN M/R-42-A // P634‑311‑653
