Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: CB2 open 3p
031 086
0: No
[spacer]
MAIN: CB3 open 3p
031 087
0: No
[spacer]
MAIN: CB4 open 3p
031 088
0: No
[spacer]
MAIN: CB1 closed 3p
031 042
0: No
[spacer]
MAIN: CB2 closed 3p
031 089
0: No
[spacer]
MAIN: CB3 closed 3p
031 090
0: No
[spacer]
MAIN: CB4 closed 3p
031 091
0: No
[spacer]
MAIN: CB1 pos.sig. implaus
031 041
0: No
[spacer]
MAIN: CB2 pos.sig. implaus
031 049
0: No
[spacer]
MAIN: CB3 pos.sig. implaus
031 051
0: No
[spacer]
MAIN: CB4 pos.sig. implaus
031 059
0: No
[spacer]
MAIN: Trip cmd. blocked
021 013
1: Yes Fig. 3-62, (p. 3-93)
[spacer]
MAIN: Latch. trip c. reset
040 139
0: No Fig. 3-62, (p. 3-93)
[spacer]
MAIN: Gen. trip command 1
036 071
0: No Fig. 3-62, (p. 3-93)
Fig. 3-132, (p. 3-180)
[spacer]
MAIN: Gen. trip command 2
036 022
0: No
[spacer]
MAIN: Gen. trip command 3
036 113
0: No
[spacer]
MAIN: Gen. trip command 4
036 114
0: No
[spacer]
MAIN: Gen. trip signal
036 251
0: No Fig. 3-62, (p. 3-93)
