Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
SFMON: Iref, d inval. rang
091 016
0: No Fig. 3-86, (p. 3-126)
[spacer]
SFMON: Matching fail. end a
091 000
0: No Fig. 3-86, (p. 3-126)
[spacer]
SFMON: Matching fail. end b
091 001
0: No Fig. 3-86, (p. 3-126)
[spacer]
SFMON: Matching fail. end c
091 002
0: No Fig. 3-86, (p. 3-126)
[spacer]
SFMON: Matching fail. end d
091 017
0: No Fig. 3-86, (p. 3-126)
[spacer]
SFMON: Ratio mtch.fact.inv.
091 004
0: No
[spacer]
SFMON: 2nd match.fact. inv.
091 006
0: No Fig. 3-86, (p. 3-126)
[spacer]
SFMON: Inv.range Iref REF_1
091 105
0: No Fig. 3-100, (p. 3-144)
[spacer]
SFMON: Inv.range Iref REF_2
091 115
0: No
[spacer]
SFMON: Inv.range Iref REF_3
091 125
0: No
[spacer]
SFMON: Match.f. kam,N REF_1
091 101
0: No Fig. 3-100, (p. 3-144)
[spacer]
SFMON: Match.f. kam,Y REF_1
091 102
0: No Fig. 3-100, (p. 3-144)
[spacer]
SFMON: Match.f. kam,N REF_2
091 111
0: No
[spacer]
SFMON: Match.f. kam,Y REF_2
091 112
0: No
[spacer]
SFMON: Match.f. kam,N REF_3
091 121
0: No
[spacer]
SFMON: Rat.mtch.f.inv.REF_1
091 103
0: No
[spacer]
SFMON: Rat.mtch.f.inv.REF_2
091 113
0: No
[spacer]
SFMON: Rat.mtch.f.inv.REF_3
091 123
0: No
[spacer]
SFMON: Min.mtch.f.inv.REF_1
091 104
0: No Fig. 3-100, (p. 3-144)
P634 8 Information and Control Functions
8-86 P634/EN M/R-42-A // P634‑311‑653
