Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
SFMON: Meas. circ. I faulty
091 018
0: No Fig. 3-58, (p. 3-90)
Fig. 3-158, (p. 3-203)
[spacer]
SFMON: Meas. c. I faulty, a
091 026
0: No Fig. 3-157, (p. 3-203)
[spacer]
SFMON: Meas. c. I faulty, b
091 027
0: No
[spacer]
SFMON: Meas. c. I faulty, c
091 028
0: No
[spacer]
SFMON: Meas. c. I faulty, d
091 029
0: No
[spacer]
SFMON: Invalid charact. V/f
091 011
0: No
[spacer]
SFMON: Invalid SW vers DHMI
093 145
0: No
[spacer]
SFMON: Invalid scaling BCD
093 124
0: No
[spacer]
SFMON: Invalid scaling A-1
093 114
0: No Fig. 3-36, (p. 3-58)
[spacer]
SFMON: Invalid scaling A-2
093 115
0: No
[spacer]
SFMON: Invalid scaling IDC
093 116
0: No Fig. 3-26, (p. 3-42)
[spacer]
SFMON: PT100 open circuit
098 024
0: No Fig. 3-28, (p. 3-44)
[spacer]
SFMON: Overload 20 mA input
098 025
0: No Fig. 3-26, (p. 3-42)
[spacer]
SFMON: Open circ. 20mA inp.
098 026
0: No Fig. 3-26, (p. 3-42)
[spacer]
SFMON: Setting error f<>
098 028
0: No Fig. 3-140, (p. 3-188)
[spacer]
SFMON: Iref, a inval. range
091 007
0: No Fig. 3-86, (p. 3-126)
[spacer]
SFMON: Iref, b inval. range
091 008
0: No Fig. 3-86, (p. 3-126)
[spacer]
SFMON: Iref, c inval. range
091 009
0: No Fig. 3-86, (p. 3-126)
