Micom P634 - Page 688

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
LOGIC: Output126
047 122
0: No
[spacer]
LOGIC: Output126 (t)
047 123
0: No
[spacer]
LOGIC: Output127
047 124
0: No
[spacer]
LOGIC: Output127 (t)
047 125
0: No
[spacer]
LOGIC: Output128
047 126
0: No
[spacer]
LOGIC: Output128 (t)
047 127
0: No
Parameter Address
Default Min Max Unit Logic Diagram
Programmable Logic
LOG_2: Enabled
011 138
0: No Fig. 3-176, (p. 3-222)
[spacer]
LOG_2: Output 1
052 032
0: No Fig. 3-176, (p. 3-222)
[spacer]
LOG_2: Output 1 (t)
052 033
0: No Fig. 3-176, (p. 3-222)
[spacer]
LOG_2: Output 2
052 034
0: No
[spacer]
LOG_2: Output 2 (t)
052 035
0: No
[spacer]
LOG_2: Output 3
052 036
0: No
[spacer]
LOG_2: Output 3 (t)
052 037
0: No
[spacer]
LOG_2: Output 4
052 038
0: No
[spacer]
LOG_2: Output 4 (t)
052 039
0: No
P634 8 Information and Control Functions
8-150 P634/EN M/R-42-A // P634‑311‑653
