Micom P634 - Page 705

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
FT_DA: Restrain. current 1
005 083
Not measured 0.00 99.00 Iref Fig. 3-80, (p. 3-116)
[spacer]
Display of restraining current, measuring system 1, referred to I
ref
.
[spacer]
FT_DA: Diff. current 2
006 082
Not measured 0.00 99.00 Iref Fig. 3-80, (p. 3-116)
[spacer]
Display of differential current, measuring system 2, referred to I
ref
.
[spacer]
FT_DA: Diff.current 2(2*f0)
006 084
Not measured 0.00 99.00 Iref Fig. 3-80, (p. 3-116)
[spacer]
Display of second harmonic in differential current, measuring system 2, referred
to I
ref
.
[spacer]
FT_DA: Diff.current 2(5*f0)
006 085
Not measured 0.00 99.00 Iref Fig. 3-80, (p. 3-116)
[spacer]
Display of the fifth harmonic component of the differential current, measuring
system 1, referred to I
ref
.
[spacer]
FT_DA: Restrain. current 2
006 083
Not measured 0.00 99.00 Iref Fig. 3-80, (p. 3-116)
[spacer]
Display of restraining current, measuring system 2, referred to I
ref
.
[spacer]
FT_DA: Diff. current 3
007 082
Not measured 0.00 99.00 Iref Fig. 3-80, (p. 3-116)
[spacer]
Display of the differential current for measuring system 1, 2 or 3, respectively,
referred to I
ref
.
[spacer]
FT_DA: Diff.current 3(2*f0)
007 084
Not measured 0.00 99.00 Iref Fig. 3-80, (p. 3-116)
[spacer]
Display of the second harmonic component of the differential current for
measuring system 1, 2 or 3, respectively, referred to I
ref
.
[spacer]
FT_DA: Diff.current 3(5*f0)
007 085
Not measured 0.00 99.00 Iref Fig. 3-80, (p. 3-116)
[spacer]
Display of the fifth harmonic component of the differential current for measuring
system 1, 2 or 3, respectively, referred to I
ref
.
[spacer]
FT_DA: Restrain. current 3
007 083
Not measured 0.00 99.00 Iref Fig. 3-80, (p. 3-116)
[spacer]
Display of the restraining current for measuring system 1, 2 or 3, respectively,
referred to I
ref
.
[spacer]
FT_DA: Diff. current REF_1
025 082
Not measured 0.00 99.00 Iref Fig. 3-81, (p. 3-117)
