Parameter Address
[spacer]
SFMON: Iref, d inval. rang
091 016
[spacer]
The reference current determined by the P634 for differential protection is not
within the permissible range.
Device reaction: Protection is blocked.
“Warning” output relay: Updating
“Blocked/faulty” output relay: –
[spacer]
SFMON: Matching fail. end a
091 000
[spacer]
SFMON: Matching fail. end b
091 001
[spacer]
SFMON: Matching fail. end c
091 002
[spacer]
SFMON: Matching fail. end d
091 017
[spacer]
The calculated amplitude matching factor of the differential protection function
is above the permissible range.
Device reaction: Protection is blocked.
“Warning” output relay: Updating
“Blocked/faulty” output relay: –
[spacer]
SFMON: Ratio mtch.fact.inv.
091 004
[spacer]
The ratio of the amplitude matching factors for differential protection is not
within the permissible range.
Device reaction: Protection is blocked.
“Warning” output relay: Updating
“Blocked/faulty” output relay: –
[spacer]
SFMON: 2nd match.fact. inv.
091 006
[spacer]
The second highest amplitude matching factor for differential protection is
smaller than permitted.
Device reaction: Protection is blocked.
“Warning” output relay: Updating
“Blocked/faulty” output relay: –
[spacer]
SFMON: Inv.range Iref REF_1
091 105
[spacer]
SFMON: Inv.range Iref REF_2
091 115
[spacer]
SFMON: Inv.range Iref REF_3
091 125
[spacer]
The reference current determined by the P634 for ground differential protection
is not within the permissible range.
Device reaction: Protection is blocked.
“Warning” output relay: Updating
“Blocked/faulty” output relay: –
[spacer]
SFMON: Match.f. kam,N REF_1
091 101
[spacer]
SFMON: Match.f. kam,Y REF_1
091 102
[spacer]
SFMON: Match.f. kam,N REF_2
091 111
[spacer]
SFMON: Match.f. kam,Y REF_2
091 112
