PCWS 2015 Setup Guide - 2nd Edition 3-37
What’s Inside?
Installing Options
3. Power-off the unit and attach the keyed 4-Pin Mini-DIN connector to the
‘Customer Display’ connector on the IO Panel.
4. The LCD Pole Display is automatically detected by the API at power-up.
Testing the Integrated and Pole LCD Customer Display
5. From the Windows Desktop double tap the DiagnosticsUtility Shortcut.
o The DiagUtility Main Screen is displayed.
6. Touch the ‘Cust Disp’ tab. Press the [Send] button to send a message to the
customer display.
o The message should display on the LCD Customer Display.
