PCWS 2015 Setup Guide - 2nd Edition 4-7
Installing and Operating the Workstation 2015
The IO Panel
Rear Display
This connector is reserved for the Integrated 240x64 LCD Customer Display.
10/100/1000 Ethernet
The PCWS 2015 includes a 10/100/1000 Ethernet Controller with a UTP
modular connector. The modular connector features an integrated isolation
transformer as well as a link status and network activity indicators. The
interface is fully IEEE 802.3 compliant.
COM 2
COM2 is a standard RS232 port based on the DB9 male connector.
COM 1 +5V/+9V/+12V Select
COM 1 is an industry standard powered RS232 Port based on the DB9 male
connector.
The powered voltage appears on pin-9 of the DB9 connector. By default +5V
appears on this pin. To change the voltage start the workstation with a USB
Keyboard attached and press [F2] to enter the BIOS Setup Menu. Proceed to
the Advanced Tab, then scroll down to ‘Special Configuration’ and press enter.
Scroll to the ‘COM Port Voltage’ field and press [Enter] to select the desired
RS232 voltage.
/ OPT
This RJ45 knock out is reserved for the a Mini-PCI Modem or other future
Mini-PCI option.
VGA
The PCWS 2015 supports dual independent displays allowing the desktop to
be displayed across two monitors.
+5V/+12V Select - USB 6
The USB6 connector combines a USB 2.0 compatible interface with either
+5V, or +12V.
Two optional dongles are available, one for each voltage. Each dongle
terminates with a standard Powered USB connector identified by its color.
IDN
The modular IDN port resides on COM4 and is physically identical to the
RS422-A and RS422-B ports on the Workstation 4 and 4 LX, KWS4, and
KW270, as well the single IDN port on the Workstation 5, Workstation 5A and
PCWS 2010.
