1-18 PCWS 2015 Setup Guide - 2nd Edition
What is the PCWS 2015
Specifications
Specifications
The PCWS 2015 conforms to the following specifications.
Specification Parameters
Processor Selections Intel Celeron P4505, Dual Core 1.8GHz, or
Intel i5-520, Dual Core, 2.4GHz
IO Controller QM57 Platform Controller Hub
Display 15” TFT LCD (1024x768)
Touchscreen EloTouchSystems Five-wire resistive, 100
thousand points-per-square inch resolution
rated at a screen life of over 35 million
touches in one location.
Capacitive option available.
Display Backlights LED Backlights with three intensity settings
programmable through the PCWS API.
Real Time Clock 100-year calendar with alarm features and
century roll-over, includes 242 bytes of battery
backed CMOS RAM.
Memory 2 SO-DIMM Sockets - Max 8GB DDR3 1066
Mag Stripe Reader 3-Track ABA compatible.
Optional Customer Displays 240x64 STN graphics based LCD
Protege Customer Display System
USB Ports Fourteen USB 2.0 Ports
> Eight Internal
> Six external (Four USB type A, two MICROS
Powered USB). External USB ports can be
disabled.
LAN Interface 10/100/1000 Ethernet - Modular RJ45
Serial Ports 1 DB9 RS232 Powered Serial w/ handshake
1 DB9 RS232 Serial /w handshake
1 Modular RS232 Serial /w handshake
1 Modular RS422/RS232 Serial (IDN)
Input Voltage Universal Input - 85 to 264VAC, 47 to 63Hz.
Input Power 35W Typical
BTU/Hour 120 Typical, 290 Maximum
Storage Temperature -25°C (-13°F) to 80°C (176°F)
Operating Temperature 0°C (32°F) to 45°C (113°F), 90% relative
humidity max
