Microsens MS400870M Series - Page 52

52
VLAN ID will be assigned to untagged frames
received on the interface. The default setting
is 1.
<port_list>: 1~26
<pvid>:1~4094
For example:
Console(config-vlan)# pvid 1-4,10-15,18,19 1
egress <port_list> <normal |
untag>
To specify normal or untag to each port.
<port_list>: 1~26
<normal | untag> The default setting to all
ports is “Normal”.
For example:
Console(config-vlan)# egress 1-4,10-15,18,19
untag
