9-5
UP-DOWN
1. Rotate the control knob to highlight the UP-DOWN option, and press.
2. If the
mark is displayed at the lower right of the TIME field, you can rotate the control
knob anticlockwise to page down and review the trend data of earlier time.
3. If the
mark is displayed at the upper right of the TIME field, you can rotate the control
knob clockwise to page up and review the trend data of later time.
L-RIGHT
1. Rotate the control knob to highlight the L-RIGHT option, and then press.
2. Rotate the control knob to select a parameters set.
The “>” mark on the right of the parameter names indicates the following page is available, and
the “<” mark on the left of the parameter names indicates the previous page is available.
3. The parameter names and the trend data changes with the selected parameter set.
REC
The REC option allows you to print out the trend data of the currently displayed parameter(s).
Mark Event
If an event is marked A, B, C or D, the mark ( A, B, C or D ) will be displayed aside the mark
time on the trend table.
