Mindray DPM 4 Operator's Manual

3-6
3.4.10 CF Storage Card
1. Power off the monitor;
2. Press down the lever (See Figure 1).
3. Take out the model card (See Figure 2).
4. Plug the CF storage card (See Figure 3).
5. The lever will then bounce out (See Figure 4).
To unplug the CF storage card, follow the procedure below:
1. Power off the monitor.
2. Press down the lever (See Figure 1).
3. Unplug the CF storage card.
4. Plug the model card.
Caution
z DO NOT plug or unplug the CF storage card when the monitor is powered on.
Lever
(1)
Model card
(2)
(3)
(4)

Mindray DPM 4 Specifications

General

Brand	Mindray
Model	DPM 4
Category	Medical Equipment
Language	English
