13-1
13 TEMP Monitoring
13.1 Overview
The monitor is able to use two temperature probes simultaneously, to obtain two temperature
values and the difference between them. The measurement values are displayed in the TEMP
parameter window as shown below.
Figure 13-1 TEMP Parameter Window
1. TEMP label: Selecting this label opens the TEMP SETUP menu.
2. Temperature unit: ℃ or ℉.
3. T1: Temperature channel 1. Displays the temperature measured at temperature channel 1.
4. T2: Temperature channel 2. Displays the temperature measured at temperature channel 2.
5. TD: Temperature difference, namely the difference between temperature 1 and temperature
2.
1
4
2
3
5
