5-6
5.5 Large Font Screen
To enter the following screen, open FACE SELECT menu, select LARGE FONT SCREEN, and
then select EXIT.
Figure 5-6 Large Font Screen
As shown above, the HR, SpO
2
and NIBP values (diastolic pressure, mean pressure and systolic
pressure) are displayed in large font. The ECG and SpO
2
waveforms are displayed on the upper
left of the screen. In case the ECG, SpO
2
or NIBP parameter module is turned off, the
corresponding parameters and waveform disappear. If all the three modules are closed, no
waveform or parameter is displayed on the screen.
NOTE
z When you open a menu in the large font screen mode, the monitor will enter the
standard screen automatically. When you exit the menu, the monitor will return
to the large font screen.
z If MULTI-LEADS DISPLAY is selected in the ECG SETUP menu, the monitor
cannot enter the large font screen.
