A-4
A.6 Wireless Network
Standards IEEE 802.11g, Wi-Fi compatible
Frequenct range 2.412 to 2.462GHz
China America Canada Europe Spain France Japan
1 to 11 10, 11 2
Operating channel
For other country, please refer to your local law.
Safe distance 10 m (a circle centering AP with the diameter of 10 m)
A.7 Signal Output Specifications
Standards
Meets the requirements of EC60601-1 for short-circuit
protection and leakage current
Output impedance 50Ω
ECG analog output
Bandwidth (-3dB; reference
frequency: 10Hz)
Diagnostic mode:
Monitor mode:
Surgery mode:
0.05 to 100 Hz (812A module)
0.05 to 150 Hz (M08A module)
0.5 to 40 Hz
1 to 20 Hz
Maximum propagation delay 25 ms (In DIAGNOSTIC mode, NOTCH is OFF)
Sensitivity 1 V/mV± 5%
PACE rejection/enhancement No pace rejection or enhancement
IBP analog output
Bandwidth 0 to 12.5 Hz (-3 dB, reference frequency: 1 Hz)
Maximum propagation Delay 55 ms (the filter function is disabled)
Sensitivity 1 V/100 mmHg ±5%
Nurse call output
Driver Relay
Electrical specifications ≤60W, ≤2A, ≤36VDC, ≤25VAC
Conducting resistance < 1Ω
Isolation voltage > 1500 VAC
Signal type Normally open or normally closed, selectable
Defibrillator synchronization pulse
Maximum time delay 35 ms (R-wave peak to leading edge of the pulse)
Amplitude 3.5 V (min) at 3 mA sourcing; 0.8 V (max) at 1 mA sinking
Pulse width 100 ms ±10%
Rising and falling time < 3 ms
VGA
Connector type 15-PIN D-sub socket
Signal RGB: 0.7 Vp-p/75Ω;
Horizontal/vertical synchronization: TTL level
