A-3
A.4 Hardware Specifications
Physical
Size 261 × 240 × 171mm (width×height×depth)
Weight < 5 kg (With no accessory and battery)
Display
Type Color TFT LCD
Size 8.4 inches (diagonal)
Resolution 800×600 pixels
Recorder
Type Thermal dot array
Horizontal resolution 160 dots/cm (at 25 mm/s recording rate)
Vertical resolution 80 dots/cm
Width of the recorder paper 50 mm
Length of the recorder paper 20 m
Recording rate 25 mm/s, 50 mm/s
Recorded waveforms 3
LED indicator
Alarm indicator 1 (yellow and red)
AC power indicator 1 (green)
Battery indicator 1 (green)
Audio indicator
Speaker
Giving audio alarms (45 to 85 dB), keypad tones, and
heartbeat/pulse tone.
Supporting PITCH TONE and multi-level volume.
Audio alarms comply withEN 60601-1-8 and IEC60601-1-8.
Connectors
Power supply 1 AC power connector
Parameter ECG, RESP, TEMP, SpO2, NIBP, IBP, CO2
Network 1 standard RJ45 network connector, 100 BASE-TX
VGA 1 standard color VGA monitor connector, 15-PIN D-sub
Auxiliary output 1 BNC connector
Equipotentiality 1 equipotential grounding connector
A.5 Data Storage
Trend data
Long trend: 96 hours, resolution 1min, 5 min or 10 min.
Short trend: 1 hour, resolution 1 s or 5 s.
Alarm events
70 alarm events and associated waveforms (with user
selectable waveform length 8s, 16 or 32).
NIBP measurements
800 NIBP groups, including systolic pressures, mean pressures,
diastolic pressures and measurement time.
