3-3
3.4 Installation Method
3.4.1 Bracket Mounting
For details, please refer to the corresponding instructions for use of bracket mounting.
3.4.2 Connecting to AC Power Supply
1. Use the original three-wire AC power cord.
2. Connect the power cord to the receptacle for AC power cord on the rear panel of the
monitor.
3. Connect the other end of the power cord to a compatible 3-prong hospital grade AC power
outlet.
The 3-prong power outlet must be ground. If it is doubted, contact related personnel of the
hospital.
WARNING
z Do not use three-wire to two-wire adapter with this instrument.
z To avoid unexpected power interruption, do no use power outlet with a
wall-mounted switch control.
3.4.3 Connecting to DC Power Supply
Select the specified DC-AC inverter which is in compliance with IEC60950. Install and use the
inverter by referring to the DC-AC inverter’s Instructions for Use.
3.4.4 Installing the Battery
If the monitor is to be powered by the internal battery, install the battery following the steps as
below:
1. Slide the battery door toward the rear of the monitor to open it.
2. Press the battery catch to the upper using one finger.
3. Insert the battery into the battery slot per the “+” and “-” indications.
4. Release the battery catch, and it will fix the battery.
5. Close the battery door.
WARNING
z Make sure the battery door is securely latched. Falling batteries could seriously or
fatally injure a patient.
3.4.5 Connecting Patient Sensors and Probes
Connect the necessary patient sensors or probes to the monitor. For details, see the chapters for
specific parameter monitoring in the following pages, or corresponding instructions for sensors
and probes.
