2-1
2 The Basics
2.1 Monitor Description
This monitor integrates the functions of parameter measurement, waveform monitoring, freezing,
and recording, etc. Its color TFT liquid crystal display is able to show patient parameters and
waveforms clearly. The monitor also features compact size, lightweight, easy-to-carry handle and
built-in battery, which make it portable, especially in hospital transport. The compact control
panel and control knob, and the easy-to-use menu system enable you to freeze, record, or perform
other operations conveniently. Besides, this monitor can be connected with the central monitoring
system whereby a monitoring network will be formed.
2.1.1 Intended Use
This monitor is intended to be used for monitoring, recording, and alarming of multiple
physiological parameters (see 2.1.4 Functions) on single adult, pediatric and neonate patient. For
arrhythmia detection and ST Segment analysis, the target populations are adult and pediatric only.
This monitor is to be used in healthcare facilities by trained clinical physicians or appropriate
medical staff under the direction of physicians. It is not intended for out-of-hospital transfer or
home use.
WARNING
z The operator of the monitor must be well trained. Any operation by
unauthorized or non-trained personnel is forbidden.
z The physiological waveforms and parameters and the alarm information
displayed by the monitor are only for the reference of physicians, but cannot be
used directly to determine the clinical treatment.
2.1.2 Contraindications
None.
2.1.3 Components
This monitor consists of parameter measuring modules, blood pressure cuff, ECG and IBP cables,
SpO
2
sensors, and CO
2
measuring components. Some of the components are optional and may
not apply to your patient monitor.
