8-1
8 Recording
8.1 Overview
A thermal recorder can be equipped with the monitor. The performance of the recorder is
described as below.
îš„ Records patient information and parameters.
îš„ Records a maximum of three waveforms.
îš„ The optional recording rates: 25mm/s and 50mm/s.
îš„ The recording grid is optional.
îš„ Multiple recording types are supported.
For details about the recorder setup, please refer to 4.4.4 Recorder Setup.
8.2 Recording Types
The monitor supports the following types of recordings:
îš„ Real-time recording: continuous real-time recording or 8-second real-time recording.
îš„ Automatic recording.
îš„ Alarm recording: measured parameter alarm recording.
îš„ Frozen waveform recording.
îš„ Trend graph/table recording: trend graph, trend table, NIBP measurement, alarm event or
arrhythmia recording.
îš„ Titration table recording.
îš„ OxyCRG recording.
îš„ Monitor status information recording.
Real-time recording
Pressing the RECORD key on the control panel, the real-time recording starts and the current
parameters and waveforms are recorded. As described in 4.4.4Recorder Setup, you can set the RT
REC TIME to 8S or CONTINUUM in the RECORD menu. You can also select the three
waveforms (REC WAVE 1, REC WAVE 2 and REC WAVE 3) to be recorded. If one or two of the
three waveforms is set to OFF, the recorder will merely print out the waveforms set to ON and all
the measured parameters; if all the three waveforms are set to OFF, the recorder will only print all
the measured parameters.
Automatic recording
The monitor starts recording at the selected interval (TIMING REC TIME) and record for 8s
waveforms automatically. For details, see 4.4.4Recorder Setup.
