Mindray DPM 4 Operator's Manual

5-4
5.4 Viewbed Screen
This monitor can view one parameter waveform and measured data from another patient monitor
(viewbed monitor) on the same monitoring network. To enter the following screen, open FACE
SELECT menu, select VIEWBED SCREEN, and then select EXIT. When connecting by wireless
network (if your monitor has this feature), viewbed function is disabled.
Figure 5-5 Viewbed Screen
The monitor you are viewing from is called “host monitor”. The monitor being viewed is called
“viewbed monitor”. The viewbed screen is always displayed at the lower part of the host
monitor’s waveform area. As shown in Figure 5-5, it consists of the following parts.
1
2
3
6
4
5
