1.2 Equipment Symbols
NOTE
z Some symbols may not appear on your equipment.
Attention: Consult accompanying documents (this manual).
Power ON/OFF
Power ON/OFF
Alternating current (AC)
Battery indicator
Type CF applied part. The unit displaying this symbol contains an
F-type isolated (floating) patient part providing a high degree of
protection against shock, and is suitable for use during defibrillation.
TYPE BF applied part. Defibrillator-proof protection against
electrical shock.
Equipotentiality
Auxiliary output
Network connector
VGA connector
AG module connector
Gas inlet
Gas outlet
