Mindray DPM 4 Operator's Manual

C-11
C.2.13 AG Module Alarm Messages
Alarm message A B L Cause Measure
AG SENSOR OFF No Yes 3 The AG sensor is
not properly
connected or is
disconnected.
Make sure the AG
sensor is properly
connected.
AG NO WATERTRAP No Yes 3 The AG water trap is
disconnected from
the monitor.
Make sure the water
trap is properly
connected.
CHANGE AG
WATERTRAP
Yes No 2 The AG water trap is
replaced.
Wait until the water
trap has been changed.
AG WATERTRAP TYPE
WRONG
Yes No 2 The AG water trap is
of a wrong type.
Replace with a water
trap of a correct type.
AG USA ERROR Yes No 2 AG module fault. Contact us to get rid of
the fault.
AG PARAMAGNETIC
O2 ERR
Yes No 2
AG GALVANIC O2
ERROR
Yes No 1
AG OXIMA DEPLETION
WARN
Yes No 2
AG OXIMA DEPLETION
ERR
Yes No 2
O
2
module fault. Contact us to get rid of
the fault.
AG OCCLUSION Yes No 1 The actual pump rate
of the AG module is
<20ml/min, which
exceeds 1 second.
Remove the block of
the airway.
AG SELF-TEST ERR Yes No 1 AG module fails or
fails to communicate
with the host.
Unplug and re-plug the
module and then restart
the monitor, or plug the
AG module in another
monitor to check if it
operates properly.
AG HARDWARE MALF No No 1 AG module
hardware failure.
The module enters
the standby mode or
stop AG monitoring.
Remove the AG
module from the
monitor and send for
authorized maintenance
personnel.
AG HARDWARE
ERROR
Yes No 2 AG module
hardware fault. The
module remains AG
monitoring.
AG DATA LIMIT
ERROR
Yes No 2 AG module fault.
AG ZREF FAIL Yes No 3 Failure in AG
module zeroing.
AG CAL FAIL Yes No 1 Failure in AG
module calibration.
Unplug and re-plug the
module and then restart
the monitor.
CO2 ACCURACY
UNSEPCIFIED
Yes No 3 The measurement is
out of specified
Check that appropriate
gas is used and the
