Mindray DPM 4 Operator's Manual

4-12
 RT REC TIME
Real-time recording time
Options: CONTINUAL and 8s.
 TIMING REC TIME
Timing recording time
The interval between automatic recordings.
Options: OFF, 10MIN, 20MIN, 30MIN, 40MIN, 50MIN,
1HOUR, 2HOURS, 3HOURS and 4HOURS. The monitor will
start recording at the selected interval, record for 8s and stop
automatically.
NOTE
z TIMING REC TIME cannot be saved after the monitor is turned off. But it can be
saved as the user default configuration.
z RT REC TIME has priority over TIMING REC TIME.
 REC RATE
Recording rate
Options: 25.0 and 50.0; unit: mm/s;
 REC GRID
Recording grid
ON: You can select ON to print a grid on the recorder paper;
OFF: You can select OFF to print without grid on the recorder
paper.
 CLEAR REC TASK
Clear recording task
This key allows you to clear all current recording tasks.

Mindray DPM 4 Specifications

General

Brand	Mindray
Model	DPM 4
Category	Medical Equipment
Language	English
