Comparator operation is as

same as its intention.

Connect securely according to the

paragraph 4−3−3 and 7−1−2.

Inform Minebea about the contents of

failure and situation at site in details.

Contact output chatters.

Contact output isn’t ON.

Connecting method is good.

Set value is good.

Confirmation/change for set value

should be made according to the

paragraph 7−2−1.

Confirmation/change for comparator

operation, comparative target for

comparator should be mode according

to the paragraph 7−2−2, 7−2−3, and

7−2−4.

Apply setting for hysteresis according

to the paragraph 7−2−5.

Following causes are considered.

Failure in contact by using other than

the rated capacity of contact.

Contact capacity AC125 V 0.1 A or

DC30 V 0.5 A.

Failure in customer’s input circuit.

Confirm the contact output signal by

referring to the paragraph 7−13

Check mode.

YES
