145
Outputs other
than BCD.
Intended value
doesn’t output.
BCD output
doesn’t vary.
12
Setting is correct.
By referring to the paragraph 9−2.,
connect(wiring) with external equipment.
Select the target of BCD output.
・ FUNC−20 Selection of the target of
BCD output.
(Refer to 8. Function Mode)
Adjust the setting related with BCD
output to the specifications for external
connecting instrument.
・ FUNC−21 Selection of output logic
for BCD data.
・ FUNC−22 Selection of output logic
for BCD polarity.
・ FUNC−23 Selection of output logic
for BCD flag.
・ FUNC−25 Selection of output logic
for P.C.
(Refer to the section 8 Function Mode)
Set the HOLD input open.
NO
YES
YES
YES
YES
NO
NO
NO
Inform Minebea about the contents of
failure and situation at site in details.
