Minebea CSD-814B User Manual

67
Procedures
・ Confirmation on contact output signal.
Press the key.
The load display will show “OUT”.
By pressing the key again, the load display
will change to “−OUT−”.
At the same time, each contact output will vary
by the key operation in the right figure.
7
“All OFF”
↓↑
“S4”
↓↑
“S3”
↓↑
“S0”
↓↑
“S2”
↓↑
“S1”
↓↑
“RUN”
↓↑
“RUN”
“ERROR”
↓↑
“All ON”
:↓ :↑
: makes each contact output
ON one by one from the
upper to the lower in the
left figure.
: makes each contact output
ON one by one from the
lower to the upper in the
left figure.
Display S0 : S0 Output
S1 : S1 Output
S2 : S2 Output
S3 : S3 Output
S4 : S4 Output
RUN : RUN Output
CHECK : ERROR Output
