2. Product presentation
MiR1350 User Guide (en) 05/2022 - v.1.2 ©Copyright 2021-2022: Mobile Industrial Robots A/S. 20
The control panel buttons
Figure 2.5. The MiR1350 control panel.
Pos. Description Pos. Description
1 Manual stop button 2 Resume button
3 Power button 4 Operating mode key
Table 2.2.
Identification of items on the control panel in Figure 2.5
Manual stop button
Pressing this button stops the robot. After pressing this button, you must press
the Resume button to let the robot continue operating.
Color indication:
•
Red: It is possible to engage the Manual stop.
