* 1 The logical station No. is a logical number specified as the "station No." in the Device monitor
utility or user program (MELSEC data link function).
Table9.52 Explanation of Target setting screen
Item Description
Target module
Select the module to be set.
(Initial value: "1 slot", Setting range: "1 slot" to "8 slot")
Logical Sta. No.
*1
Specify the logical station No. of the module selected in "Target module".
(Initial value: 65, Setting range: 65 to 239)
Sta. No.
Set the station No. of the CC-Link module controlled by the multiple CPU system.
(Initial value: 0, Setting range: 0 to 63)
Targe t CPU
Set the CPU (CPU No. used in the multiple CPU system) to be accessed.
(Initial value: 1, Setting range: 1 to 4)
button
Registers the set or modified data (Logical Sta. No., Sta. No., Target CPU) to the target
setting list.
Target setting list
Displays a list of the Logical Sta. Nos. set to the module selected in "Target module" and
the corresponding station Nos. and target CPUs.
button
Displays the data in the row (Logical Sta. No.) selected in the Target setting list in the
Logical Sta. No. area.
(Double-clicking the desired row can also chage the Logical Sta. No. area setting.)
button
Deletes the line (Logical Sta. No.) selected in the Target setting list.
Module information
Other station monitor Online operation
Parameter setting
Target setting
Test
Set
Change
Delete
