Mitsubishi MELSEC Q Series User Manual

9
UTILITY OPERATION
9.3 CC-Link utility
9.3.7 Operating Test screen
9 - 85
9
UTILITY OPERATION
10
FUNCTIONS AND PROGRAMMING
11
OVERVIEW OF MULTIPLE CPU SYSTEM
12
MULTIPLE CPU SYSTEM CONFIGURATION
13
MULTIPLE CPU SYSTEM CONCEPT
14
COMMUNICATIONS BETWEEN CPU MODULES
15
PARAMETERS ADDED FOR MULTIPLE CPU
16
PRECAUTIONS FOR USE OF AnS SERIES MODULE
(b) Network test operation procedure
The network test can be executed only when the data link status ( Section
9.3.2) of the CC-Link module is "In data link" or "During Auto-Returning".
1) Setting
Select whether to start or stop data link and click the button to start the
network test.
2) Test result
The test result is displayed on the following screen.
Refer to the following for details of the error code.
Section 18.4.1
Figure 9.70 Network test screen
Figure 9.71 Network test result
OK
