9 - 96
9.4 MELSECNET/H Utility
9.4.2 Operating Module information screen
9
UTILITY OPERATION
(a) Details of reasons for transmission interruption
The following lists the reasons for transmission interruption.
(b) Details of reasons for transmission stop
The following indicates the details of reasons for transmission stop.
Table9.60 Details of reasons for transmission interruption
Display Description/Action
Normal Communicating normally
Offline Offline
Offline test Offline test being conducted.
Initial status Error occurred. (Error code: F101, F102, F105)
Shift control station Error occurred. (Error code: F104, F106)
Online testing Error occurred. (Error code: F103, F109, F10A)
Baton disappearance Error occurred. (Error code: F107)
Baton repetition Error occurred. (Error code: F108)
Same station present Error occurred. (Error code: F10B)
Control station repetition Error occurred. (Error code: F10C)
Reception retry error Error occurred. (Error code: F10E)
Transmission retry error Error occurred. (Error code: F10F)
Timeout error Error occurred. (Error code: F110)
Line trouble Error occurred. (Error code: F112)
Disconnecting Error occurred. (Error code: F11B)
No baton to local station Error occurred. (Error code: F11F)
Error code: XX Error occurred. (Refer to the displayed error code section.)
Table9.61 Details of reasons for transmission stop
Display Description
Normal Communicating normally
Stop instruction present
(All)
Cyclic transmission of all stations was stopped from the self
or other station.
Stop instruction present
(Self)
Cyclic transmission of the self station was stopped.
Stop instruction present
(Station )
Cyclic transmission of the self station was stopped from the
other station (Station No. ).
Common parameter No parameter can be received.
Illegal parameter The set parameter is erroneous.
Error self CPU
Medium/critical error occurred at the CPU module of the
self station.
Suspend communication Data link error occurred at the self station.
To Next Page
