Mitsubishi MELSEC Q Series User Manual

9
UTILITY OPERATION
9.4 MELSECNET/H Utility
9.4.2 Operating Module information screen
9 - 95
9
UTILITY OPERATION
10
FUNCTIONS AND PROGRAMMING
11
OVERVIEW OF MULTIPLE CPU SYSTEM
12
MULTIPLE CPU SYSTEM CONFIGURATION
13
MULTIPLE CPU SYSTEM CONCEPT
14
COMMUNICATIONS BETWEEN CPU MODULES
15
PARAMETERS ADDED FOR MULTIPLE CPU
16
PRECAUTIONS FOR USE OF AnS SERIES MODULE
Remark
The information of the "Module detail information" screen is based on the time
when the "Module detail information" screen is opened.
To update the information, close and reopen the "Module detail information"
screen.
Table9.59 Explanation of Module detail information screen (Continued)
Item Description
Correspon-
ding SB
Correspon-
ding SW
Data link information Displays the data link status of MELSECNET/H.
Total number of linked
stations
Displays the total number of linked stations on MELSECNET/
H.
SW0059
Station of maximum
normal transmission
Displays the maximum number of normal communicating
stations on MELSECNET/H.
SW005A
Station of maximum data
link
Displays the maximum number of data link stations on
MELSECNET/H.
SW005B
Transmission status
Displays the transmission status of MELSECNET/H.
( This section (1)(a))
SW0047
Reason for transmission
interruption
Displays the reason for transmission interruption on
MELSECNET/H.
( This section (2)(a))
SW0048
Reason for transmission
stop
Displays the reason for transmission stop on MELSECNET/H.
( This section (2)(b))
SW0049
