9.4 MELSECNET/H Utility
9.4.4 Operating Other station monitor screen
9
UTILITY OPERATION
Table9.65 Explanation of Other station monitor screen (Continued)
Item Description
Correspon-
ding SB
Correspon-
ding SW
button
Stops monitoring of the MELSECNET/H module.
When monitoring is stopped, this button changes to
.
Self station information
Displays the self station information of the MELSECNET/H
module.
Start I/O No.
Displays the start I/O No. of the self station.
(Display range: 0000 to 0FE0)
Network No.
Displays the network No. of the self station.
(Display range: 1 to 239, "-")
SW0040
Group No.
Displays the group No. of the self station.
(Display range: 0 to 32, "-")
SW0041
Sta. No.
Displays the station No. of the self station.
(Display range: 1 to 64, "-")
SW0042
Network
Displays the network of the MELSECNET/H module.
(Display item: "MELSECNET/H Extended (Loop)",
"MELSECNET/H Extended (Bus)", "MELSECNET/H (Loop)",
"MELSECNET/H (Bus)", "MELSECNET/10 (Loop)",
"MELSECNET/10 (Bus)")
SB0057,
SB005A
SW0046
Type
Displays the type of the self station.
(Display item: "Control station", "Normal station")
SB0044
Other station information
Displays the error occurrence condition of the other stations.
( This section (2))
Double-clicking each item opens the corresponding screen
showing the detailed information.
button
Opens the details screen and displays further information of
the selected item.( This section (2))
Other station information Displays the error items and statuses in "Other station
information" and "Error status" respectively.
Error status
Module information Online operation Parameter setting Target settingError history monitor
Other station monitor
Stop monitor
Start monitor
Details
