9.4 MELSECNET/H Utility
9.4.7 Operating Target setting screen
9
UTILITY OPERATION
* 1 The Logical station No. is a logical number specified as "station No." in the Device monitor utility
or user program (MELSEC data link function).
Table9.88 Explanation of Target setting screen (Continued)
Item Description
Logical Sta. No.
*1
Specify the logical station No. of the module selected in "Target module".
(Initial value: 65, Setting range: 65 to 239)
Network No.
Set the network No. of the MELSECNET/H module controlled by the multiple CPU
system. (Initial value: 1, Setting range: 1 to 239)
Sta. No.
Set the station No. of the MELSECNET/H module controlled by the multiple CPU
system.
(Initial value: 1, Setting range: 1 to 64)
Targe t CPU
Set the CPU (CPU No. used in the multiple CPU system) to be accessed.
(Initial value: 1, Setting range: 1 to 4)
button
Registers the set or modified data (Logical Sta. No., Network No., Sta. No., Target CPU)
to the target setting list.
Target setting list
Displays a list of the Logical Sta. Nos. set to the module selected in "Target module" and
the corresponding network Nos., station Nos. and target CPUs.
button
Displays the data in the row (Logical Sta. No.) selected in the Target setting list in the
Logical Sta. No. area.
(Double-clicking the desired row can also change the Logical Sta. No. area setting.)
button
Deletes the line (Logical Sta. No.) selected in the Target setting list.
