10 - 23
10.2 Programming Using Bus Interface Functions
10.2.6 Precautions for program debugging
10
FUNCTIONS AND PROGRAMMING
(3) Symbol information synchronization setting
To debug the user program, the symbol information of the C Controller module and
that of the development environment (personal computer) must be synchronized.
1) Start Tornado.
2) Choose [Tools] [Target Server] [Configure] from the menu bar to open the
"Configure Target Severs" dialog box.
3) Select "Core File and Symbols" in the "Target Server Properties" pull-down
menu.
4) Select the "Synchronize Target/Host Symbol Tables" check box.
5) Click the button.
6) Select [Tools] [Options] from the menu bar to open the "Options" dialog box,
and select the "Tornado Registry" tab.
7) Select the "Remote registry" radio button, and set the IP address or host name
of the development environment (personal computer).
8) Click the button.
Remark
Refer to the Tornado manual for other debugging methods.
Figure 10.8 Symbol information synchronization setting
Figure 10.9 Development environment (personal computer) IP address setting
OK
3)
4)
OK
7)
To Next Page
