SYSTEM CONFIGURATION
2.1 System Configuration
2.1.1 Devices to be used
2 - 3
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
FUNCTIONS
5
SETTING AND PROCEDURES
6
I/O NUMBER ASSIGNMENT
7
MEMORIES AND FILES
8
INSTALLING / UNINSTALLING
(2) When the slim type main base unit (Q3 SB) is used
Remark
• Refer to Section 2.1.4 (2) for available base units and power supply modules.
• Refer to Section 2.2.1 for available I/O modules and intelligent function modules.
Figure 2.2 System configuration when slim type main base unit is used
Slim type main base unit
CompactFlash card
(to be purchased separately)
C Controller module
Q series power supply, I/O, Intelligent function modules
Battery
